ALL THE WATTS, NONE OF THE DECIBELS.
CORSAIR RMx series fully modular power supplies are built with the highest quality components to deliver 80 PLUS Gold efficient power to your PC, with virtually silent operation.
80 PLUS GOLD CERTIFIED
High efficiency operation for lower power consumption, less noise and cooler temperatures.
TUNED FOR LOW NOISE OPERATION
A specially set fan curve ensures that, even at full load, fan noise is kept to a minimum.
ZERO RPM FAN MODE
At low and medium loads the cooling fan switches off entirely for near-silent operation.
100% ALL JAPANESE 105°C CAPACITORS
Premium internal components ensure unwavering power delivery and long-term reliability.
FULLY MODULAR CABLES
Only connect the cables your system needs, making clean and tidy builds easier.
COMPACT SIZE
A 160mm-long casing ensures an easy fit in almost all modern enthusiast PC cases.
TEN-YEAR WARRANTY
Your guarantee of reliable operation that will last across several system builds.
- 80 PLUS Gold efficiency, delivering 90% energy efficiency at real world load conditions
- ZeroRPM mode for fanless operation at low loads and outstanding noise reduction
- 135mm thermally controlled fan spins up as needed
- Fully modular cables for easy installation, less clutter, and helps maximize airflow through your computer’s chassis
- Engineered to meet maximum power output at a server-grade 50°C temperature rating
- Over-voltage protection, under-voltage protection, short circuit protection, over power protection, and over temperature protection provide maximum safety to your critical system components
- Safety and Agency Approvals: FCC, ICES, CE, UL / CUL, CSA, C-Tick/RCM, TUV, CB, CU, KC Mark, RoHS, WEEE, RoHS (China), REACH
Artikelnummer fabrikant:
CP-9020180-EU
Aansluitingen
CPU stroom aansluiting (4+4 pin) :
EPS power connector (8-pin):
Floppy drive stroom aansluiting(en):
2
Moederbord stroom aansluiting:
20+4 pin ATX
Molex stroom aansluiting(en):
8
PCI Express stroom aansluiting(en) (6+2 pin):
6
SATA stroom aansluiting(en):
10
Verbindingstechnologie:
Volledig modulair
Certificaten
80 PLUS certificatie:
80 PLUS Gold
Energie
Gecombineerde power (+12V):
150 W, 850 W
Gecombineerde power (+3.3V):
150 W
Gecombineerde power (+5Vsb):
15 W
Gecombineerde power (-12V):
9,6 W
Ingangsfrequentie:
47 - 63 Hz
Ingangsspanning:
100 - 240 V
Max output current (+12V):
70,8 A
Max output current (+3.3V):
25 A
Max output current (+5V):
25 A
Max output current (+5Vsb):
3 A
Max output current (-12V):
0,8 A
Maximale ingangsstroom (@110V):
12 A
Fysieke eigenschappen
Kleur van het product:
Zwart
Koeling
Aantal ventilatoren:
1 ventilator(en)
Diameter ventilator:
13,5 cm
Ventilator positie:
Boven
Ventilator snelheid:
0 - 950 RPM
Technische details
Gemiddelde levensduur (MTBF):
100000 uur
Kogellager techniek:
Gegroefd
